Documentation

KRASPAN products have technical licenses, certificates, reports and calculations on testing results of fitness for construction applications on RF territory.

	Certificate of quality management system compliance to the requirements of ISO 9001:2008 standard. As applied to engineering and production of suspended facade systems.
	Certificate of quality management system compliance as applied to engineering and assembling of suspended facade systems and translucent constructions GOST ISO 9001:2008.
	Certificate of ecological management system compliance as applied to engineering and assembling of suspended facade systems and translucent constructions GOSTR ISO 14001:2004.
	Technical certificates and technical estimations of serviceability of products in building on the territory of RF, FAI “Federal Center of Technical Estimation of Products in Construction”, Moscow.  For slabs and panels: KraspanComposite-ST KraspanComposite-AL KraspanFibercementColor KraspanFibercementStone KraspanCeramicgranite KraspanMetalColor KMEW
	For aluminum subsystems L-BA Kraspan faced with: cassettes made of KraspanComposite-ST composite material cassettes made of KraspanComposite-AL composite material panels made of KraspanComposite-AL composite material fiber cement slabs KraspanFibercementColor, KraspanFibercementStone ceramic granite slabs KraspanCeramicgranite KraspanGranite slabs made of natural stone
	For subsystems made of galvanized iron Kraspan L-BCт or of stainless steel Kraspan L-BCтH faced with: cassettes made of KraspanComposite-ST composite material cassettes made of KraspanComposite-AL composite material panels made of KraspanComposite-AL composite material fiber cement slabs KraspanFibercementColor, KraspanFibercementStone ceramic granite slabs KraspanCeramicgranite KraspanGranite slabs made of natural stone metal panels KraspanMetalColor and stainless steel sheet
	For subsystems made of galvanized iron Kraspan U-BCт or of stainless steel Kraspan U-BCтH faced with: cassettes made of KraspanComposite-ST composite material cassettes made of KraspanComposite-AL composite material Panels made of KraspanComposite-AL composite material Panels made of KraspanComposite-St composite material fiber cement slabs KraspanFibercementColor, ceramic granite slabs KraspanCeramicgranite metal panels KraspanMetalColor and shaped steel
	Compliance certificates in “Rosstroisertificatsia”, “KRASNOYARSKSTROISERTIFICATSIA” and “RegionStroiSertificatsia” systems

GOSTR ISO 14001:2004 in respect to projecting and assembling of suspended facade systems and translucent constructions.

Assembling and projecting works authorization

• SPO (self-regulating organization) Certificate on approval for works on formation of project documentation influencing security of capital construction objects No. CPO-П-104-2463063989-042-4
• SPO Certificate on authorization to works on construction, reconstruction and capital repair of capital construction objects No. C/0390/246306 3989/2010/CPO-C-011-28052009 of 25.05.2010.

Partnership certificates:

• Certificate of Cembrit OY official dealer
• Certificate of KMEW official distributor

Seismic resistance testing of KRASPAN systems

Seismic resistance testing of KRASPAN SFS has been executed in Central Building Construction Research Institute named after Kucherenko V.A. The Institute accommodates unique bench equipment for research on protection against vibration and dynamics of buildings and constructions exposed to natural and technogenic loads (earthquakes).

Test purpose: to define reliability of facade fixing to a wall and to study behavior of KRASPAN construction elements under vibration loads.

Load tests completed successfully:

• in basement: 9 points
• in the upper part of a facade: 9-12 points

1. L-ВСт(Н)Kraspan facade system using ceramic granite slab. Bonding technique: tingle
2. L-BA Kraspan facade system using KraspanFibercementColor facade slabs. Bonding technique: clench

KRASPAN systems have been experimentally and theoretically tested for work in severe natural environment. All KRASPAN systems of every type of bonding and different combinations of metal frames, facade panels and slabs are given testing reports.

KRASPAN systems seismic resistance is 9 points by MSK-64 scale, which means they can be safely use in mass construction buildings in all regions of seismic hazard.

Experimental and theoretical research on definition of suspended facade systems bearing capacity; Kraspan L-ВСт and Kraspan L-ВА.

Experimental and theoretical research was held in Building Construction Department of Federal Siberian University Institution of Civil Engineering. The research included studying of work and analyzing of strain-stress distribution of a load-carrying frame of facade systems with a ventilated air gap.

Test purpose: definition of subsystem bearing capacity and maximum vertical load; study of an altered scheme and calculation model specification.

The results have shown that the constructions meet strength and toughness requirements of the Construction Directives and Rules for vertical and horizontal wind loads in I-VI wind districts with respect to wind loading vibration for a building of up to 150m high. Albums of technical solutions have been issued for all nomenclature of KRASPAN system constructions on the base of these results.

Attention: Kraspan, Ltd. has exclusive rights to manufacture of sets of gauge materials and cantilevers for KARSPAN SFS. Certificate of trademark No. 247382. Patens No. 32807, No. 34557 and No. 34588. Sets of suspended ventilated facade.
